Fleet # –
Year – 2001
Make – CAT
Model – 420D
Body Style – IT Loader Backhoe
Serial Number – CAT0420DCBLN01471
Odometer Numbers –
Hours – 4388
Engine Make/Model – Cat 3054T 85 Net HP, turbocharged
Cyl – 4
Fuel Type – Diesel
Transmission Name – Cat Power Shuttle, 4 forward speeds and 4 reverse speeds with full synchromesh gears
Transmission Type – Auto
Single Axle/Dual Axle – Single Axle Single Wheel
Tire Size/Type – Front: 340/80R18, Rear: 19.5LR24
Tire Condition – Good
Plow Size –
Dump Box Size –
Drivetrain – 4WD
GVWR – 15,772Lbs
Does the unit operate? – Yes
Does the vehicle start? – Yes
Are keys available? – Yes
Ownership Information – Bill of Sale Only (No Title)
Mechanical Condition – Fair
Mechanical Notes – Engine is fair to good, and the drive train is good. The hydraulic lines are tight. Currently the throttle cable sometimes sticks and needs brake work. The rear hitch cable needs replacing as well. View images.
Body Condition – Fair
Body Notes – Solid with average wear, cab glass is in-tact. Has always been stored indoors. It comes with a 86"L front loader bucket and a rear 5-tooth 24" type digging bucket.
Interior Condition – Fair
Misc Info –
The following general information is web-sourced and may contain variances from the subject unit:
2001 Caterpillar 420D-IT (Integrated Toolcarrier) is a highly versatile, 4WD loader backhoe renowned for its durability and hydraulic capability.
Engine Performance
- Model: Powered by a Cat 3054T (4-cylinder, turbocharged diesel engine).
- Power Output: Delivers 85 net horsepower (88 gross HP) at 2,200 RPM.
- Design Features: Built with a direct-injection fuel system for responsive power delivery. It includes a dry-type, radial-seal air cleaner and a standard thermal starting aid for dependable cold-weather operation.
Powertrain & Transmission
- Transmission Type: Cat Power Shuttle transmission.
- Gears: 4 forward speeds and 4 reverse speeds with full synchromesh gears.
- Operation: Features hydraulically shifted directional clutches that allow the operator to shift between forward and reverse on-the-go without a clutching pedal.
- Travel Speed: Maxes out at 20.4 mph in both directions.
Integrated Toolcarrier (IT) & Key Features
The "IT" designation sets this unit apart from a standard 420D:
- Parallel Lift Linkage: The loader features a unique mechanical parallel-lift geometry. This keeps your front loader bucket or pallet forks completely level throughout the entire lift cycle, preventing material spills.
- Quick Coupler: Comes standard with an integrated hydraulic quick coupler on the front, letting you swap the 86-inch, 950-lb front bucket for forks, brooms, or material handling arms in seconds from inside the cab.
- Hydraulics: Utilizes a closed-center, load-sensing variable displacement piston pump flowing at 43.1 GPM. This ensures full hydraulic power even when the engine is running at low RPMs.
Digging Capabilities
- Rear Bucket: Equipped with a 24-inch, 5-tooth heavy-duty digging bucket.
- Dig Depth: The standard stick configuration provides a maximum digging depth of 14.4 feet, backed by an impressive 14,712 lbs of backhoe bucket digging force.
